Folding Frame
The Beluga frame and fork are made of industry-grade Aluminum Grade 6061. Our new design is sleek, light, and strong enough for a Cyclist weighing 300lbs to feel comfortable on it.
Easily folds down to a compact size for easy storage and transportation.
Motor
Customized 500W high-speed geared brushless motor with enough pulling power so you can effortlessly conquer an 18° climb. Brushless motors are smoother, more efficient and have no magnetic drag when you ride the bike without any power.
Product name: Beluga | Motor: MXUS 500W brushless geared DC motor | Brakes: 160mm disc brakes |
Model name: QSEB 04 | Rated output power: 500W | Rim: 20-inch Al-Alloy blade |
Size:65.5*25.5*46.5inch | Motor efficiency: ?78% | Tire: Kenda 20x4.25" |
Folding Size: 34.25*18.50*28.35inch | Rated RPM: 310±10r/min | Chain wheel: Prowheel 52T |
Wheelbase:43.5inch | Rated voltage: 48V | Freewheel: Shimano 14-28T |
Net weight: 51lbs | Max torque: 40N.m | Derailleur: Shimano 7 speed |
Range: 25 Miles?PAS? | Overcurrent protection: 15±1A | Chain: KMC |
Max. load: 300lbs | Low-voltage protection: 30±1V | Handlebar: Promax |
Max. speed: 20MPH | Kwh: ?1.2Kw.h | Display: Kunteng LCD |
Charging time: 7 Hrs | Modes: 5 levels | Controller: Kunteng sine wave FOC |
Battery type: Samsung Lithium-ion | Tire diameter: 20x4.25 Inch | Brake levers: Al-Alloy e-bike lever |
Battery capacity: 48V 10.5Ah | Frame: 20 inch 6061 Al-Alloy Foldable | Saddle: KNUS |
Noise : ? 62 dB(A) | Front fork: 20 inch 6061 Al-Alloy | Pedal: Foldable Pedals |
